Atlas BP8000 User Manual

Parts Lists 37
BP8000
Item Part# Description Qty. Note
59 205007B Offside column 1
60 209049 Plastic pulley 3
61 203012 Offside safety lock 1
62 203013 Coupling 2
63 203014 Safety Block (Secondly) 1
64
205026
Socket Bolt 2
64A
610026
Self locking Nut M5 2
65 420049 Split pin 4
66 209059B Anchor bolt 12
66A 209053B Stackable Adapter (5”) 4
Oil Hose, Fitting & Cable
Item Part# Description Qty. Note
67 209060 90° Fitting for Power Unit 1
68 201081 Oil hose 1
69 207024 90° Fitting 2
69A 201082 Extended Straight Fitting 2
70 420097 90° Fitting 2
71 207034 Oil Hose 2
71A 211016 T Fitting 1
72 205009 Cable 2
73 209066 Cable Nut 4
