Atlas BP8000 User Manual

Parts Lists 36
BP8000
Item Part# Description Qty. Note
38 209020 Plastic ball for arm lock 4
39 209021 Hex nut 8
40 209022 Washer 10
41 209023A Arm lock 4
41A 210041 Limit Ring 4
42 209024 Arm lock bar 4
43 209025 Hair pin 4
44 209026 Spring 4
45 209027 Protective rubber set 4
46 209038 Hex bolt 6
47 209039 Lock washer 10
48 205004 Offside carriage 1
49 209035 Moon gear 4
50 209032 Socket bolt 12
50A 209034 Lock washer 12
50B 209033 Washer 16
51 520023 Snap ring 4
52 209030A Lifting Arm Pin 4
53 205005 Connecting plate 2
54 209043 Hex Bolt 4
55 209046 Hex Bolt 4
56 205006 Top plate 2
57 209045 Big Pulley 2
58 209057A Bronze bushing for pulley 6
