Parts Lists 35
BP8000
Item Part# Description Qty. Note
20B
205010 Safety cable 1
21 201046A Rubber Pad Assembly 4
21A 420138 Socket bolt 4
21B 209134 Rubber Pad 4
21C 680030C Rubber Pad Frame 4
22 209057 Small pulley 4
23 209056 Self locking nut 2
24 201043A Lifting Arm 4
24A 201047 Outer Arm 4
24B 201048 Middle Arm 4
24C 201049A Inner Arm 4
25 201010 Chain connector 4
26 201009A Chain 2
27 201008A Hydraulic cylinder 2
28 203040 Pin for chain pulley 2
29 203004A Bronze bush for chain pulley 4
30 201006 Chain pulley 2
31 201005 Split pin 2
32 201004 Chain pulley assembly 2
33 205003 Power side Carriage 1
34 206044 Slider 16
35 209016 Carriage plastic cover 2
36 206045 Protective rubber 2
37 206046 Self-tapping screw 4
To Next Page
