Steps Of Installation 21

BP8000

2. Lower the carriages down to the lowest position, then use the 17# wrench to

loosen the nut.

Fig. 23

3. Adjust the arm lock. Follow the arrow direction.

Fig. 24

4. Adjust the teeth of arm lock assembly. Make it mesh with the gear on the

lifting arm. Tighten the hex bolts on the arm lock assembly.

Fig. 25

Loosen the nut

Arm lock
