ATN Zebra 16 Operator's And Safety Manual

OPERATOR AND SAFETY MANUAL
1NO0035UK-05
Zebra 16
11
CHARACTERISTICS
Zebra 16
Maximum working height
16.40 m
Max floor height
14.40 m
Min floor height
0.40 m
Max outreach (on axis)
8.90 m
Max working reach (on axis)
9.40 m
Structure orientation
360° (Non continuous)
Work platform rotation
2x 90°
Work platform dimensions
0.86 x 1.80 m
Max number of people on the platform
2
Platform capacity
230 kg
Maximum allowable wind
12.5 m/s (45 km/h)
Maximum manual force
400 Newton
Maximum allowable tilt
5°
Maximum allowable slope
45%
Overall length (transport position)
7.12 m
Overall length (storage position)
5.12 m
Overall Width
2.24 m
Overall height (transport position)
2.25 m
Wheelbase
2.10 m
Ground clearance
0.40 m
Oscillating axle steering travel
0.23 m (14°)
Number of driving wheels
4
Number of steering wheels
2
Tyres (solid tyres)
Standard
830x285(530)
Option
36x14-20
Turning radius
Inside
1.72 m
Outside
4.55 m
Travel speed
Transport position
6km/h
With platform elevated
0.85km/h
Empty weight
7,200kg
Floor load on a
Wheel (*)
Force
4,200 daN
Contact pressure
14.5 kg/cm² (1422 kPa)
(*): The floor load values indicated may vary depending on the configuration/position of the machine.
an adequate safety margin with respect to these values should always be kept.
The weighted acoustic pressure level A on the platform's control station is dB(A).
The weighted acoustic power level emitted by the machine (LWA) is 104 dB (test method
according to European directive 2000/14/CE relating to noise emissions in the environment of
equipment intended to be used outside buildings – Appendix III, Section B, Points 0 and 1).
The total value of the vibrations to which the hand-arm system is exposed does not exceed 2.5m/s².
The average maximum quadratic value weighted by the acceleration frequency to which the whole
body is exposed does not exceed 0.5m/s².
Due to constant improvements made to its products, ATN reserves the right to alter their
specifications and equipment without notice.
