ATN Zebra 16 Operator's And Safety Manual

OPERATOR AND SAFETY MANUAL
12
1NO0035UK-05
Zebra 16
MOVEMENT DURATIONS
Zebra 16
Arm 1
Rise
Idle
29 to 32 seconds
High regime
17 to 20 seconds
Descent
Idle
24 to 27 seconds
High regime
21 to 24 seconds
Arm 2
Rise
Idle
25 to 28 seconds
High regime
14 to 17 seconds
Descent
Idle
17 to 20 seconds
High regime
13 to 17 seconds
Arm 3
Rise
16 to 19 seconds
Descent
18 to 21 seconds
Telescope
Out
Idle
30 to 33 seconds
High regime
17 to 20 seconds
In
Idle
18 to 21 seconds
High regime
16 to 19 seconds
Orientation (end to end)
110 to 120 seconds
Rotation (end to end)
10 to 15 seconds
Note: The movement speeds may vary according to the telescope position, the adjustment
of the limit switches and the adjustment of the load holding valves.
