ATN Zebra 16 Operator's And Safety Manual

OPERATOR AND SAFETY MANUAL
56
1NO0035UK-05
Zebra 16
8.2.1 ENGINE / TRANSMISSION (F1)
1- Entry parameters - Movement/steering joystick.
2- Variable rate pump control value
3- Parameters - Steering movement.
4- Light - Parking brake: the icon turns grey when the brake is deactivated.
The arrows light up when the corresponding movement is commanded.
Proportional valve control setpoint (PV2)
Steering hydraulic circuit pressure
The lights arrows light up when the corresponding movement is commanded.
Joystick setpoint value - Steering movement
Joystick setpoint value - Movement
(1)
(6)
(7)
(5)
(8)
(10)
(11)
(2)
(12)
(9)
(3)
(4)
