5- Light - Movement speed selection.
The icon that corresponds to the movement speed selected on the platform control
station is displayed:
Slow speed
Ramp speed (max torque)
Quick speed
6- Hydraulic oil temperature.
7- Transmission hydraulic circuit pressure
8- Light – Diesel engine start authorised.
9- Light – Preheating / Start countdown.
10- Engine speed (RPM)
11- Light – Engine speed fault (option).
The light comes on if the slow down speed is too high
12- Lights – Diesel engine faults.
Engine oil pressure fault
Engine temperature fault
Alternator fault
