ATN Zebra 16 User Manual

OPERATOR’S AND SAFETY HANDBOOK
1NO0060EN-00
Zebra 12 – Zebra 16
69
REP
DESCRIPTION
NB.
CODE
OPERATION
INTERVALS
LUB
PTS.
J
50
(1)
200H
400H
1200H
1
Hydraulic tank
1
H46
Level check
(4)
X
Oil change
X
(2)
2
Hydraulic filter (Return)
1
-
Filter element replacement
X
X
3
Hydraulic filter (Pressure)
1
-
Filter element replacement
X
X
4
Engine oil
1
HM
Level check
X
Oil change
X
X
(3)
5
Engine oil filter
1
-
Replacement
X
X
(3)
6
Fuel filter
1
-
Filter element replacement
X
X
(3)
7
Fuel pre-filter
1
-
Replacement
X
8
Fuel tank
1
-
Oil change and cleaning of
residues
X
9
Cooling fluid
1
-
Level check
X
10
Air Filter
1
-
Cleaning
X
Filter element replacement
X
(3)
11
Oscillating axle grease
nipples
2
GR
Application: Grease gun
X
12
Grease nipples – Arm
pins
4
GR
Application: Grease gun
X
13
Arm 1 synchronisation
tie-rod grease nipples
2
GR
Application: Grease gun
X
(6)
14
Lift cylinder grease
nipples
2
GR
Application: Grease gun
X
15
Load control system
greaser nipples
4
GR
Application: Grease gun
X
16
Turntable bearing teeth
1
GR
Remove the used grease
Application: Brush
X
(5)
17
Turntable bearing grease
nipples.
2
GR
Application: Grease gun
X
(5)
18
Grease nipples turntable
worm gear reducer
3
GR
Application: Grease gun
X
(5)
19
Outrigger ball joint grease
nipples.
4
GR
Application: Grease gun
X
(7)
Notes :
J : At the beginning of each day or after each operator change.
(1) : After the first 50 hours' operation.
(2): At the interval indicated or every 2 years.
(3): At the interval indicated or every year.
(4) : The oil level must appear in the level light window.
(5) : Turn the structure to distribute the grease.
(6) : Zebra 16 only.
(7) : Zebra 16 Stab only.
8.3 HOSES
Each time you start working with the machine, you have to check hoses statement and their
connections. Each hose with a leak, pinch, abrasion or in such of other wear has to be replaced.

ATN Zebra 16 Specifications

General

Brand	ATN
Model	Zebra 16
Category	Boom Lifts
Language	English
