ATN Zebra 16 - Control Screen Functions; 9.1 Control Screen Overview

OPERATOR’S AND SAFETY HANDBOOK
1NO0060EN-00
Zebra 12 – Zebra 16
72
9.1 CONTROL SCREEN
The machine is fitted with an onboard tactile screen used for adjustments / diagnostics.
Info and contact ATN: by clicking on the logo, you
will access the different contacts at ATN
Model and S/N
Date and time
Safety indicators / Machine faults
1
2
3
4
Page
closing
1
3
2
6
5
4
7
8
