Atomos Ninja Blade – User Manual Edition 1: Feb 2014 4
Spinning Disk Drives (HDD)
These are the raw storage medium for Ninja Blade. You can use either
WUDGLWLRQDO´VSLQQLQJµGLVNVRUWKHQHZVROLGVWDWHRQHV&KRRVH½”
spinning drives if your Ninja Blade is going to be attached to a tripod or if
it is not going to be subject to excessive vibration. For harsher conditions,
choose a solid state drive.
Which drives should you use?
There are so many drives available, and newer models appear all the
time. We are not able to test all drives but here are some guidelines.
Speed and reliability are the main factors. Here are a few things to
bear in mind:
• Disk drive data rates tend to be given in megaBYTES per second, and
FRGHFGDWDUDWHVDUHQRUPDOO\JLYHQLQPHJD%,76SHUVHFRQG,W·VYHU\
HDV\WRJHWFRQIXVHG%XWWKHUH·VQRQHHGWREHEHFDXVHDOO\RXKDYH
WRGRWRFRQYHUWPHJDELWVWRPHJDE\WHVLVGLYLGHE\6RLI\RX·UH
UHFRUGLQJDWPHJD%,76SHUVHFRQGWKDW·VJRLQJWRUHVXOWLQ
megaBYTES per second, which is 27.5 megaBYTES per second.
• We recommend at least 7200 RPM drives. Just remember that the
KLJKHUWKHELWUDWHRIWKHFRGHF\RX·UHXVLQJWKHIDVWHUWKHGULYHQHHGV
to be.
Atomos regularly test hard drives – please check this link before
purchasing drives: http://www.atomos.com/discovery-what-drives/
Solid State Drives (SSDs)
These are Flash memory devices that come in the same form-factor as
2 ½” disk drives, and they are fully supported by the Ninja Blade. See
the section below about when you should consider using SSDs.
Mechanical Shock and Vibration
Hard disks are precision mechanical devices that need to be handled
carefully. You will be using the same type of drives that are normally used
in notebook computers, and you can use this as a guide to whether you
need to use mechanical drives or Solid State ones for any proposed
projects. If you think a particular usage scenario would be suitable for a
notebook computer, then it will probably be OK for a mechanical drive
inside a Ninja Blade. If you think the drive inside your notebook might
VXIIHUGDPDJHWKHQGRQ·WXVHDPHFKDQLFDOGULYH
:HFDQ·WJLYHULJLGJXLGHOLQHVEHFDXVHWKHUHDUHVRPDQ\GLIIHUHQWNLQGV
RIGULYHVHDFKZLWKGLIIHUHQWPHFKDQLFDOSURSHUWLHV<RXPD\HYHQÀQG
variations between drives of the same type.
What we have found is that mechanical drives are suitable for most
SXUSRVHVWKDWGRQ·WLQYROYHKDUVKYLEUDWLRQRUPHFKDQLFDOVKRFNV7KH\
will be perfect for tripod-mounting, and also for the majority of hand-held
work. We would advise against hard-mounting them on moving vehicles
(but they would probably be OK if cushioned against the body of the
camera operator) and we would not advise using mechanical disks if there
is a likelihood that they might be dropped onto a hard surface.
Here are some things that you should bear in mind when using
spinning disks:
• Even though spinning drives can withstand substantial shocks when
they are not in use, they are more vulnerable when running. Harsh
treatment that may not actually damage the drive may interrupt
recordings at a much lower level of severity. We recommend that you
experiment with your drives by testing them in the conditions that you
normally work in.
• Spinning drives have a gyroscopic effect that you will feel faintly if
you rotate the Ninja Blade up or down or from side to side. They are
particularly sensitive to this type of motion. If you do this too quickly
while the drive is spinning, you may get a small gap in your recording.
• Be very gentle when changing batteries if you are recording. Practise
this manoeuvre so that you are able to do it smoothly. It is always better
to do this in-between takes.
• Do not bang or jolt the Ninja Blade while recording. Gentle and
cushioned movement may be OK.
<RXZLOOÀQGQRWLFHDEOHGLIIHUHQFHVLQWKHDELOLW\RIGULYHVWRZLWKVWDQG
shock and to continue recording during vibration and movement. As we
receive reports of drive durability and reliability, we will post them on
www.atomos.com
• Your Ninja Blade is able to detect when the drive is under stress and it
will recover from any break in a recording by waiting until the drive is
ready to continue, and then resuming from that point. If frames have
been dropped because of shock or vibration, a “Skippy” Kangaroo
symbol will appear on the home screen on the Ninja Blade, just above
the disk capacity indicator. This means that you will not normally have
to restart the Ninja Blade, even if a recording has been interrupted by
mechanical disruption to the disk drive. (see Recording and Monitoring:
Atomos Anti-shock Technology for more information)
Taking into account most usage scenarios, we think that mechanical disks
will be suitable in the majority of cases. Spinning disks are most sensitive
when they are rotating. It is obviously best to avoid dropping them but
PDQ\GLVNVQRZKDYHD´GURSGHWHFWRUµWKDWZLOOORFNWKHPRVWIUDJLOH
mechanical parts in place and protect them from surprisingly hard knocks.
We recommend that if you want to experiment with this, you do so with a
GULYHWKDWGRHVQ·WFRQWDLQWKHGD\·VVKRRW
Backing up and archiving
Remember that no storage medium, including tape, optical disks, spinning
GLVNVDQGÁDVKPHPRU\LVFRPSOHWHO\LPPXQHIURPIDLOXUH<RXVKRXOG
bear this in mind when deciding how to manage your recorded content.
At the very least, you should consider the consequences for you and your
business if your storage medium were to suffer from a sudden failure, and
you should back up your content accordingly. Hard drives that you can
XVHIRUDUFKLYLQJDUHEHFRPLQJLQFUHDVLQJO\DIIRUGDEOH<RXPD\ÀQGWKDW
it is completely feasible for your to keep your master Ninja Blade disks
RQDVKHOIMXVWOLNHWDSHVDQGDVDEDFNXSVWRUHFRSLHVRQODUJHKDUG
drives, RAID arrays or Network Attached Storage (NAS).
