C. System Overview
C.1 Equipment Parts
Front of Unit
Figure C.1: Pyrolytic Oven Front
1. Draft Inducer
2. Oxidizer Chamber
3. Blow-O󰀨 Door
4. Oven Chamber
5. Electrical Box
6. Power Light
7. HMI Touch Screen
8. USB Port
9. Power Switch
5
3
1
2
7
6
4
8
9
