MAN - Pyrolytic Oven - REV: Original | D. Installation12
D. Installation
D.1 Installation Overview
WARNING: Do not use in Class I, II or Ill locations as dened by the National Electrical Code.
CAUTION: Be sure ambient temperature does not exceed 104°F (40°C). Ambient above this
level may result in damage to controller.
NOTE: Allow at least 4 inches of space between the oven and any vertical surfaces.
NOTE: Pyro-Clean ovens are supplied with a power cord but not a plug. The plug will need to
handle 240Vac @ 30A.
WARNING: Use a properly grounded electrical outlet of correct voltage and current handling
capacity.
NOTE: Disconnect from the power supply prior to maintenance and servicing. Refer servicing to
qualied personnel.
WARNING: Do not use in the presence of ammable or combustible materials; re or explosion
may result. This device contains components which may ignite such material
NOTE: Do not put sealed containers in oven.
NOTE: A 30 amp breaker is recommended because the total load of the oven is 28 amps.
D.2 Receiving
The Pyrolytic Oven is shipped completely assembled and crated. Inspect the oven crate and any other additional
boxes or crates carefully upon receipt. If there is any sign of damage to the crate or oven, do not sign the delivery
receipt until the freight company has been notied and such damage has been noted on the receipt. Claims for
shipping damage must be made by the customer to the Freight Company and not to the distributor or manufacturer.
Remove the crate lumber carefully to avoid damaging or scratching the surface of the oven. The Pyrolytic Oven
weighs about 400 pounds crated and can be moved with a fork truck or heavy dolly while crated. Uncrated, the
oven weights slightly over 350 pounds and can be moved by hand with su󰀩cient help. Avoid excessive leverage on
