MAN - Pyrolytic Oven - REV: Original | G. Troubleshooting 31
G. Troubleshooting
G.1 Troubleshooting Electrical Problems
A ladder wiring diagram for the Pyrolytic Oven is included in this manual, along with a drawing of the inside of the
control box showing the lay-out of the parts and their identication. A qualied electrician should nd this sucient
to locate any electrical problems with the unit. The oven electrical circuit has a number of fuses, so check rst to
determine if a blown fuse is the problem. If assistance is needed to determine the problem, contact Applied Test
Systems and ask for technical help.
G.2 Manual Operation to Check Electrical Operaton
A manual operation screen is included so that all parts can be controlled manually to check operation and help
troubleshoot the system.
NOTE: In manual operation the temperature control systems will only allow the temperature to
be set to 500°F as a safety precaution.
