30 MAN - Pyrolytic Oven - REV: Original | F. Operation
start to heat to 900°F. The status display will change to “Oven Soak”.
11. In the “Oven Soak” stage, the oven will heat up creating smoke that gets burnt o in the oxidizer chamber. If the
oxidizer temperature goes over 1500°F it will shut o the oven heat until the temperature goes below 1350°F. It will
then turn the oven back on. This cycle will continue back and forth until the smoke generation dies down and the
oven temperature is stable (900°F ±10°F for 180 minutes). The oven will then heat to 950°F and the air select will
shift the air ow from the oxidizer to the oven. The status display will change to “Run Cycle”.
12. Once the oven gets to cycle temperature (950°F ±10°F) it will sit for the cycle time.
13. Once the cycle time has expired, both the oxidizer and oven chamber heat will turn o and the status display will
change to “Cool Down”.
14. When the oven temperature drops below 500°F the draft inducer and air pump will turn o and the oven door will
unlock. The status display will change to “Cycle Finished”.
15. At this point press the “End\Stop” button to return the system to “O”.
CAUTION: When the oven unlocks to allow the removal of parts, remember that they are still at
500°F and you will need protective equipment to handle them.
