ATS Pyro-Clean - Back of Unit

MAN - Pyrolytic Oven - REV: Original | C. System Overview 7
Back of Unit
1. Draft Inducer
2. Oxidizer Chamber
3. Oven Chamber
4. Electrical Control Box
5. Air Intake Filter
6. Ethernet Port
7. Draft Inducer Power Outlet
8. Power Cord
Figure C.2: Pyrolytic Oven (Rear View)
1
2
3
4
5
6
7
8
