Chapter 4
User interface & configuration
Togetaccesstothecontrolandconfigurationsettings,theAMP523/RM523should
beconnectedtoacomputerorenEthernetLANnetwork.Formoreinformationabout
networkconnectionsandsettings,seeIPbasicsinchapter6.
Thestandard(factorydefault)IPaddressoftheAMP523/RM523is192.168.0.193,
makesurethisaddressiswithintheIPrangeoftheconnectedEthernetLANnetwork
(subnetmask255.255.255.0).Ifthedefaultnetworkaddressisnotwithinrangeofyour
LANnetwork,contactyournetworkspecialist.Thenetworkaddresscanbechanged
withtheStandardWebBasedUserInterfacebutthereforeanetworkconnectionmust
bemadefirst!
Anydevice(PC,Laptop,PDAorevenaSmartphone)withawebbrowserandthe
MacromediaFlash8.0plug-in(orhigher)installed,canbeusedtocontroltheweb
baseduserinterface.
Formobiledevices,suchasPDA’s,smartphonesoreveniPhonesoriPads,special
applicationsaredevelopedtocontrolthestandardfunctionsoftheAMP523/RM523.
User interface & configuration

StartyourdefaultwebbrowserandentertheIPaddressoftheembeddedweb
serveroftheAMP523/RM523intheaddressbar.(ThefactorydefaultIPaddressis
http://192.168.0.193)
Login screen
Firsttheloginscreenwillbedisplayed.
Apasswordshouldbeenteredtogetaccesstothewebinterface.Afterthecorrect
passwordisentered,clickthe“OK”button,andyouwillberedirectedtothemain
screenoftheAMP523/RM523.(ThefactorydefaultpasswordfortheAMP523is
‘AMP523’andfortheRM523is‘RM523’.
NOTE
ThepasswordscanbechangedintheConfiguration>>Passwordsettingsmenu
