Microphone Preamplifiers
& Line Inputs
iD44 features four classic Audient
microphone preamplifiers. These preamps
are based on designs from Audient’s classic
consoles and are the same that are used
across our entire product range.
The design features discrete Class-A circuitry
providing exceedingly low distortion and
noise performance. From a sonic point of
view, iD44 is fast, open and detailed.
Amphenol™ XLR/TRS Jack combi-connectors
provide microphone and line inputs. The line
inputs are padded through the microphone
preamplfiiers.
The four microphone
preamplifiers feature:
• 58 dB of clean gain
• 48V (±4V) phantom power rated at 14mA/
channel
• >2.8kΩ input impedance which provides
a punchy tone from any microphone
transducer type
• Signal and Clip Indicators
• -10dB Pad
• 100Hz High Pass Filter to remove
unwanted rumble
Channels 1 and 2 also include an Insert
Send and Return allowing for the use of
outboard equipment while tracking.
