Dante PCIe-R Card
CONFIDENTIAL. Copyright © 2014 Audinate Pty Ltd. All Rights Reserved.
-9-
About your Dante PCIe-R
The Dante PCIe-R is a PCI Express format Dante soundcard for use with compatible PCs and Macs. It
allows the transmission and reception of up to 128 bidirectional channels of 24-bit uncompressed digital
audio data (complying with Audinate’s Dante™ audio networking standard) at sample rates up to 96kHz, or
64 bidirectional channels at 176.4 and 192kHz (24-bit).
The Dante PCIe-R has a fully compatible PCIe (PCI Express) standard interface connector allowing it to
be installed in any compatible PC or Mac.
Gigabit Ethernet connectors ensure low latency, high-quality synchronized audio with support for glitch-
free redundancy.
Dante PCIe-R Specifications
Specifications
PCI Express card Compatible with PCIe x4 slots v1.0 and above
Audio Interface Presents as standard ASIO audio interface (Windows) or
Core Audio (Mac OS X) soundcard
Audio channels 256 @ up to 96kHz (128x128)
128 @ 176.4 and 192kHz (64x64)
Supported Sample Rates 44.1, 48, 88.2, 96, 176.4 and 192kHz
Pull-up/down +4.1667, +0.1, -0.1, -4.0%
Sample bit-depth 24 bit PCM
Round Trip Latency Less than 2.99ms digital round trip to/from connected Dante audio
equipment
Onboard hardware and
software processing
High-performance hardware and on-board microprocessor performs all
packet and transport processing
Clock High quality on-board VCXO clock can provide master clock, or slave off
audio equipment;
automatic synchronization with Dante network
Dante Network interface Gigabit (1000Mbps; 1Gbps) Ethernet RJ45 connectors
Glitch-free redundancy Secondary network interface for connection to a redundant network
Full Dante implementation Compatible with all Dante-enabled audio equipment over standard
IP/Ethernet network
