AudioArts Engineering audio console r-55e - R-55 E-12 (18-Pos.) Frame; R-55 E-12 Connector Kit

W#
ITEM#
QTYDESCRIPTION
R-55e-12 18-pos. FRAME PARTS LIST
0035641MB REAR
0035661PAN BRACE
0035791MB POWER CONNECTOR BRACKET
0055394BLANK FACEPLATE FOR R-55e
0055491QMP-4 LOADED CARD ASSEMBLY
0055511MBE-5508 LOADED CARD ASSEMBLY
0055521TIMER ASSEMBLY FOR R55e-12
0055551MBR-5510 LOADED CARD ASSEMBLY
0055801R55e-12 FRAME PAN
0055831R55e-12 METERBRIDGE COVER
0055841R55e-12 METAL ARMREST
0055951R55e-12 CONNECTOR KIT
0071044LED-3 LOADED CARD
026057A1CLK-220 LENSE
1000901PAINTED MDF LEFT SIDEPLATE
1000911PAINTED MDF RIGHT SIDEPLATE
1100240.33ALUMINUM CONTINUOUS HINGE, 72"X1.06" X .040"
1302311SET RIGHT/LEFT END CAP
1302321SET FRONT/BACK FOAM INSERT
1302480.023/8" WIDE X 1/16" THICK X 100' LONG BLACK FELT STRIP
1500832.526 COND FLAT RIBBON CABLE
160046129 7/8" X 17 3/4" X 31 7/8" 275D BOX TOP
160047129 1/8" X 17 5/16" X 31 3/4" BOX BOTTOM
230020210 PIN PLUG
23002823 PIN .098" PLUG FOR #26 AWG
2300701PLASTIC SHELL CHASSIS CONNECTOR
250039116 PIN RIBBON PLUG
2600051RTS JACK
270050A8PIN M MOLEX 14-20GA REEL
2800008PATCH CLIPS
2800073PATCH CLIPS
6300044VU METER
6300084
LIGHT BOX FOR AL29 METER WITHOUT LAMP OR
LAMPHOLDER
8220071FLAT WASHER
8220081SHOULDER WASHER
823016274-40 X .250 HEX ZINC
page 11 - 30
R-55e / July 2004
