MBR-2000 MOTHER BOARD (RIGHT) PARTS LIST

220027CT2-CT5 462 PIN PC MOUNT CARDEDGE CONNECTOR

220075CT1 160 PIN BOARD-TO-BOARD FEMALE CONNECTOR

250062CT6, CT7, CT9, CT10 43 PIN .098" HEADER

250075CT11 116PIN BOXED HEADER, STRAIGHT

250077CT8 210PIN BOXED HEADER, STRAIGHT

700653PCB_MBR2000 1PRINTED CIRCUIT BOARD

page 11 - 19

R-55e / July 2004

Main Page

Default Chapter4
- Table of Contents4
Chapter 1 - Installation10
Unpacking the Console10
Countertop Mounting10
System Ground11
Power Supply13
- Failsafe Dual Redundant Supply14
- Energizing14
Audio and Control Wiring15
- Connection Procedures15
- Unbalanced Connections (Analog Audio)15
Modules Layout15
Hand Crimp Tool Wiring Instructions16
Wiring Procedure - Double Connection to One Pin18
R-55E - 12-Position Frame - Modules Layout19
R-55E 12-Position Frame - Modules Layout19
R-55E - 18-Position Frame - Modules Layout20
R-55E 18-Position Frame - Modules Layout20
R-55E 26-Position Frame - Modules Layout21
R-55E - 26-Position Frame - Modules Layout21
Chapter 2 - Quad MIC Preamp (QMP-4)23
Overview23
Internal Programming Options24
- Phantom Power24
Hook-Ups24
- Audio Input Connections24
- Audio Output Connections25
- Power Connections26
Installing the Optional Second QMP-4 MIC Preamp28
Chapter 3 - Stereo Line Input (SL-55E)30
Module Overview30
Internal Programming Options31
- Mutes31
- Timer Restart31
- Local/Ready31
- Talkback31
Hook-Ups32
- Control Connections32
- Remote on & off35
- Cough35
- Ready35
- On Tally35
- Tally B35
DB Connector Pinout Drawing36
Chapter 4 - Output Module (OM-55E)37
Module Overview37
Hook-Ups38
- DB-25 Connector - Audio38
- DB-9 Connector - Control39
DB Connector Pinout Drawing41
Chapter 5 - Control Room/Studio Module (CRS-55E)42
Module Overview42
Internal Programming Options43
- Cue Interrupt43
- Cr/Cue Mute43
- Studio Mute43
- Studio DIM43
Hook-Ups44
- Left DB-25 "A" Connector - AUDIO44
- Right DB-25 "B" Connector - AUDIO44
DB Connector Pinout Drawing47
Chapter 6 - Second Studio Module (SS-55E) - Optional48
Module Overview48
Internal Programming Options49
- Cue Interrupt49
- HDPN 3 Mute49
- Studio 2 Mute49
- Studio 2 DIM49
Hook-Ups50
- Left DB-25 "A" Connector - AUDIO50
- Right DB-25 "B" Connector - AUDIO50
- External START & STOP53
Chapter 7 - Superphone Module (SPN-55E) - Optional54
Module Overview54
- Caller Set-Ups54
Internal Programming Options55
- Mutes55
- Timer Restart55
- Gain Trimpot55
Hook-Ups55
- Audio Connections55
- Control Connections55
- Remote on & off57
- On Tally57
Chapter 8 - Line Select (LS-55E) - Optional59
Module Overview59
Internal Programming Options59
Hook-Ups60
- Left DB-25 "A" Connector - AUDIO INPUTS60
- Left DB-25 "A" Connector - AUDIO OUTPUTS60
- Right DB-25 "B" Connector - AUDIO INPUTS60
Chapter 9 - Tape Remote Module (TR-55E) - Optional63
Module Overview63
DB Connector Pinout Drawings63
- START/STOP Function Control I/O63
- Full-Function Control I/O63
Chapter 10 - Meterbridge68
Overview68
Digital Clock68
- Setting the Time69
Chapter 11 - Parts List73
- SL-55E Stereo Line Input73
- LS-55E Line Select85
- TR-55E/Ff Tape Remote (Optional)86
- TR-55E/Ss Tape Remote (Optional)87
- MBR-2000 Mother Board89
- Power Supply95
- R-55E-18 (26-Pos.) Frame99
- R-55E-12 (18-Pos.) Frame101
- R-55E-12 Connector Kit101
- R-55E-8 Connector Kit103
- R-55E Console108
Chapter 12 - Schematics and Load Sheets110
Console Flow Diagram110
Quad MIC Preamp (QMP-4) Schematic112
