NOTE: 1. CONSOLE CAN ACCOMMODATE UP TO 13 INPUT MODULES AND ACCESSORY MODULES (OPTIONAL MODULES—SUPERPHONE, LINE SELECT, AND TAPE REMOTE—CAN BE
PLACED IN ANY SLOT POS. 1-13).
2. MASTER OUTPUT, CONTROL ROOM, AND OPTIONAL SECOND STUDIO MODULES HAVE THEIR DEDICATED SLOTS (AS SHOWN).
3. SECOND STUDIO SLOT COULD BE USED ALSO FOR OPTIONAL TAPE REMOTE OR LINE SELECT MODULE.
4. LAST TWO SLOTS AT THE RIGHT END OF THE FRAME SHOULD BE USED FOR OPTIONAL LINE SELECT AND TAPE REMOTE MODULES.
page 1 – 12
R-55e-18-POSITION FRAME - MODULES LAYOUT
R-55e / May 2005
