R-55e-8 12-pos. FRAME PARTS LIST
0035491MBR-2000 LOADED CARD
0035791MB POWER CONNECTOR BRACKET
0055392BLANK FACEPLATE FOR R55e
0055491QMP-4 LOADED CARD ASSEMBLY
0055511MBE-5508 LOADED CARD ASSEMBLY
0055701R55e-8 FRAME PAN
0055711R55e-8 PAN BRACE
0055721R55e-8 MB REAR
0055731R55e-8 MB COVER
0055741R55e-8 METAL ARMREST
0055941R55e-8 CONNECTOR KIT
0071042LED-3 LOADED CARD
1000901PAINTED MDF LEFT SIDEPLATE
1000911PAINTED MDF RIGHT SIDEPLATE
1100240.3ALUMINUM CONTINUOUS HINGE, 72"X1.06" X .040"
1302311SET RIGHT/LEFT END CAP
1302321SET FRONT/BACK FOAM INSERT
1302480.0153/8" WIDE X 1/16" THICK X 100' LONG BLACK FELT STRIP
150083226 COND FLAT RIBBON CABLE
160046129 7/8" X 17 3/4" X 31 7/8" 275D BOX TOP
160047129 1/8" X 17 5/16" X 31 3/4" BOX BOTTOM
230020210 PIN RIBBON PLUG
23002823 PIN .098" PLUG FOR #26 AWG
2300701PLASTIC SHELL CHASSIS CONNECTOR
250039116 PIN RIBBON PLUG
2600051RTS JACK
270050A8PIN M MOLEX 14-20GA REEL
2800072PATCH CLIPS
6300042VU METER
6300082
LIGHT BOX FOR AL29 METER WITHOUT LAMP OR
LAMPHOLDER
8220071FLAT WASHER
8220081SHOULDER WASHER
823016194-40 X .250 HEX ZINC
8230291632 THUMB SCREW
82304544-40 X .375 THREADED HEX NYLON STANDOFF
8240324RECESSED BUMPER FOR #8 SCREW
page 11 - 32
R-55e / July 2004
