AudioArts Engineering audio console r-55e - Power Supply

W#
ITEM#
QTYDESCRIPTION
SPS-100 POWER SUPPLY PARTS LIST
0072221SPS POWER SUPPLY CABLE
0073281PSU-1 FACE BRACKET
0073552SPS-100 COVER
0073561SPS-100 CHASSIS
0073571SPS-100 RACK FACE
15001717 1/2' BLACK POWER CORD
2001168
40 AMP RIGHT ANGLE PCB MOUNT SOCKET ROHS
COMPLIANT
20012118 POSITION RECEPTACLE HOUSING
2300021GROUND LUG
230071CT1 1
POWER CORD CONNECTOR WITH PRINTED CIRCUIT
TERMINALS ROHS COMPLIANT
250062CT4, CT5 23 PIN .098" HEADER
320034U1 1
IC PROGRAMMABLE SHUNT REGULATOR ROHS
COMPLIANT
320035U3 1FLYBACK QUASY SMPS CONTROLLER
340050U2 1OPTO ROHS COMPLIANT
350000D12 1MB3510 BRIDGE RECTIFIER 35 AMP 1000 VOLT
350014D5, D6 2MBR4045 SCHOTTKY DIODE
350038D3, D4 2DIODE ROHS COMPLIANT
350039Z1 133V 5 WATT ZENER DIODE
350042D7 1800V 4A BRIDGE RECTIFIER ROHS COMPLIANT
350043D1, D2, D11, D13, D14 5DIODE ULTRA FAST SWITCHING ROHS COMPLIANT
355003D8, D10 21N4148 FAST SWITCHING SMT DIODE
355004D9 1SS14 SCHOTTKY SMT DIODE
355007Z2-Z6 55.6V SMT 3WATT ZENER DIODE ROHS COMPLIANT
360007RT1 110 OHMS 3 AMPS THERMISTOR ROHS COMPLIANT
360008V1 1250V METAL OXIDE VARISTOR ROHS COMPLIANT
400073C62, C65 2
270UF 420V ELECTROLYTIC CAPACITOR ROHS
COMPLIANT
405002C54 1CAPACITOR, 22µF 25V ELECTROLYTIC SMT
405014C15-C18, C20-C23, C27-C30, C33-C36, C53, C64 18
CAPACITOR, 330µF 35V MID/LOW ESR ELECTROLYTIC
SMT ROHS COMPLIANT
405015C14, C19, C26, C32 4
CAPACITOR, 220µF 50V MID/LOW ESR ELECTROLYTIC
SMT
405017L1-L4 4
4.7µH FERRITE CHOKE FOR BUCK REGULATOR SMT
ROHS COMPLIANT
410015C24, C25, C37, C43 4CAPACITOR, .0047µUF 1KV CERAMIC, UL RATED
410041C59, C60 22.2NF 1KV CERAMIC CAPACITOR ROHS COMPLIANT
415005C1-C8, C51, C52 10CAPACITOR, .001µF 50V CERAMIC SMT
415006C50 1CAPACITOR, .01µF 50V CERAMIC SMT
415007C48, C58 2CAPACITOR, .1µF 50V CERAMIC SMT
415009C57 1CAPACITOR, .22µF 50V CERAMIC SMT
page 11 - 25
R-55e / Nov 2007
