TMR-55e TIMER PARTS LIST (for 18-pos. frame)
435078R72, R82 288.7 KOHM 1% 1/16W 0603 RESISTOR SMT
435081R59 13.83KΩ 1% 0603 SMT RESISTOR
515001SW7 14 POSITION SMT DIP SWITCH, TAPE SEALED
605020DS12 1HIGH INTENSITY RED SMT 0603 LED VERTICAL
605023DS13 1HIGH INTENSITY GREEN SMT 0603 LED VERTICAL
610018DS8-DS11 4SINGLE SEGMENT GREEN LED DISPLAY
700815PCB_CLK55 1PRINTED CIRCUIT BOARD SMT
835002F1 1FUSE/ POLYSWITCH 1.0AMP SMT RESETABLE
