AudioArts Engineering audio console r-55e - Page 93

W#
ITEM#
QTYDESCRIPTION
TMR-55e TIMER PARTS LIST (for 18-pos. frame)
245002Y1 114 PIN .3" DIP SMT SOCKET
250014DS8-DS11 220 POSITION SNAP APART SOCKET, .1" SIL
250016CT7 0.1540 PIN BREAKAWAY HEADER STRIPS, STRAIGHT .1" SIL
250077CT2 110PIN BOXED HEADER, STRAIGHT
305054U5 1DS1706RESA TTL SMT 3.3V MicroMonitor
305057U4 1DS1306E 32KHZ RTC SMT
315077U3 1XCF01SV020CE PROM
315080U1 1XC2S30_100 SPARTAN II GATE ARRAY smt
335004Q11 1LT1117 3.3V 800mA REGULATOR SMT
335005Q12 1LT1117 2.5V 800mA REGULATOR SMT
335011Q9 1PQ05DZ11 5V 1A REGULATOR WITH ENABLE SMT T/R
345001Q10 1MMBTA05 NPN SMT TRANSISTOR
345005Q1-Q8 8FDN340P 2A P-CHANNEL FET SMT TRANSISTOR
355001D1 11N4002W RECTIFYING 1AMP SMT DIODE
355002Z1 15.1V SMT ZENER DIODE C5V1
355003D2 11N4148 FAST SWITCHING SMT DIODE
355006D3, D4 2BAT54S SCHOTTKY SMT 2 SERIES DIODES 200mA
370036Y1 1
32.768 KHZ TEMPERATURE-COMPENSATED CRYSTAL
OSCILLATOR
405008C1, C41, C42 3150UF 10V TANTALUM CAPACITOR, SMT
405011C6 1CAPACITOR, 33pF 100V CERAMIC 0603 SMT
405014C5 1
CAPACITOR, 330µF 35V MID/LOW ESR ELECTROLYTIC
SMT
415011C13, C14 2CAPACITOR, 33pF 100V CERAMIC 0603 SMT
415012C27, C29, C31, C40 4CAPACITOR, .01µF 50V CERAMIC 0603 SMT
415013C2-C4, C7-C12, C15-C18, C21-C26, C28, C32-C39 28CAPACITOR, .1µF 25V CERAMIC 0603 SMT
415015C19, C30 2CAPACITOR, 220pF 100V CERAMIC 0603 SMT
430100J3, J4 20 OHM 5% .25W JUMPER-RESISTOR
435049R45 11.0 MOHM 5% .25W MC1206 RESISTOR
435057R57 15.1 OHM 5% 1/16W 0603 RESISTOR SMT
435060R39, R40, R44, R48, R51, R53, R60, R64, R69, R80 1010.0 KOHM 1% 1/16W 0603 RESISTOR SMT
435061
R4, R7, R9, R11, R13, R15, R18, R21, R36, R37,
R58, R66, R71, R85
141.00 KOHM 1% 1/16W 0603 RESISTOR SMT
435062
R1-R3, R6, R17, R20, R41-R43, R46, R47, R49,
R50, R52
1451 OHM 1% 1/16W 0603 RESISTOR SMT
435065R62, R65, R70, R77 433 OHM 1% 1/16W 0603 RESISTOR SMT
435067
R23, R25, R27, R29, R33, R34, R38, R61, R63, R68,
R75, R76, R78, R83, R84
154.99 KOHM 1% 1/16W 0603 RESISTOR SMT
435068R54, R73 240.2 KOHM 1% 1/16W 0603 RESISTOR SMT
435070R5, R8, R10, R12, R14, R16, R19, R22, R87 9332 OHM 1% 1/16W 0603 RESISTOR SMT
435073
R24, R26, R28, R30-R32, R35, R67, R74, R79, R81,
R86, R88
13220Ω 5% 0603 SMT RESISTOR
page 11 - 23
R-55e / Sep 2004
