AudioArts Engineering audio console r-55e - Page 92

W#
ITEM#
QTYDESCRIPTION
CLK-55e CLOCK/TIMER PARTS LIST (for 26-pos. frame)
435070R5, R8, R10, R12, R14, R16, R19, R22, R87 9332 OHM 1% 1/16W 0603 RESISTOR SMT
435073
R24, R26, R28, R30-R32, R35, R67, R74, R79, R81,
R86, R88
13220Ω 5% 0603 SMT RESISTOR
435078R72, R82 288.7 KOHM 1% 1/16W 0603 RESISTOR SMT
435081R59 13.83KΩ 1% 0603 SMT RESISTOR
510094SW5 1PUSHBUTTON SWITCH GREEN LED/ NO CAP
510095SW6 1PUSHBUTTON SWITCH RED LED/ NO CAP
515001SW7 14 POSITION SMT DIP SWITCH, TAPE SEALED
530001SW5 1GREEN SWITCH CAP
530266SW6 1
CLEAR BUTTON WITH WHITE FRAME AND RED
DIFFUSER
605020DS12 1HIGH INTENSITY RED SMT 0603 LED VERTICAL
605023DS13 1HIGH INTENSITY GREEN SMT 0603 LED VERTICAL
610004DS1-DS6 6SINGLE DIGIT LED DISPLAY
610018DS8-DS11 4SINGLE SEGMENT GREEN LED DISPLAY
700815PCB_CLK55 1PRINTED CIRCUIT BOARD SMT
8230492ID=.125_OD=.187_H=.12 NYLON SPACER
835002F1 1FUSE/ POLYSWITCH 1.0AMP SMT RESETABLE
page 11 - 22
R-55e / Sep 2004
