AudioArts Engineering audio console r-55e - Page 27

page 2 – 6
R-55e / July 2004
QUAD MIC PREAMP
12 345
6
78
9
10
11
12
QMP-4 Quad Mic Preamp
Plug Terminal Pinouts
INPUT
PORTS
ANALOG
MIC 1 IN SH
MIC 1 IN LO
MIC 1 IN HI
MIC 2 IN SH
MIC 2 IN LO
MIC 2 IN HI
MIC 3 IN SH
MIC 3 IN LO
MIC 3 IN HI
MIC 4 IN SH
MIC 4 IN LO
MIC 4 IN HI
12 345
6
78
9
10
11
12
OUTPUT
PORTS
ANALOG
MIC 4 OUT HI
MIC 4 OUT LO
MIC 4 OUT SH
MIC 3 OUT HI
MIC 3 OUT LO
MIC 3 OUT SH
MIC 2 OUT HI
MIC 2 OUT LO
MIC 2 OUT SH
MIC 1 OUT HI
MIC 1 OUT LO
MIC 1 OUT SH
