AudioArts Engineering audio console r-55e - Page 76

W#
ITEM#
QTYDESCRIPTION
OM-55e OUTPUT MODULE PARTS LIST
435023
R84-R87, R89, R94, R96-R98, R100-R102,
R104-R106, R110, R112, R115, R117
194.99 KOHM 1% .25W MC1206 RESISTOR
435028R10, R13, R32, R35, R78 510.0 KOHM 1% .25W MC1206 RESISTOR
435039R39, R40, R42, R43, R45, R47, R49, R50, R108 940.2 KOHM 1% .25W MC1206 RESISTOR
435043R51 188.7 KOHM 1% .25W MC1206 RESISTOR
500014CR1-CR6 610K 15 TURN TRIM POT
500058CUE POT 110KΩ SINGLE AUDIO CONDUCTIVE PLASTIC, BOURNS
505002CR7-CR10 410K TRIM POT SMT
510097SW1 12 POLE PUSHBUTTON SWITCH, ALTERNATE ACTION
510113SW2-SW8 72 POLE PUSHBUTTON SWITCH, MOMENTARY
520053CUE KNOB 11/8" COLLET KNOB, NO POINTER, NO LINE
530079CUE CAP 1PASTEL GREEN CAP W.BLACK LINE FOR 15MM KNOB
530083
EXT/ PGM/AUD/MONO/AUTO/START-STOP
SWITCH BUTTON
6CUSTOM WHITE LIGHT PIPE BUTTON
530084RESET SWITCH BUTTON 1CUSTOM RED LIGHT PIPE BUTTON
530085HOLD SWITCH BUTTON 1CUSTOM YELLOW LIGHT PIPE BUTTON
550006K1, K2 2DPDT RELAY,5V
605010DS1, DS6 2HIGH INTENSITY AMBER SMT LED RIGHT ANGLE
605017DS4, DS8 3ULTRABRIGHT RIGHT ANGLE RED SMT
605018DS3, DS7 2ULTRABRIGHT RIGHT ANGLE GREEN SMT
605019DS5, DS9 2ULTRABRIGHT RIGHT ANGLE YELLOW SMT
700299PCB_BPSA1000 1PRINTED CIRCUIT BOARD
700655PCB_OM2000A 1PRINTED CIRCUIT BOARD
8200474D SUB STANDOFFJACK HARDWARE 3/16" LONG
8210095PEM FASTENERS
835001F1-F3 3FUSE/ POLYSWITCH .3AMP SMT RESETABLE
page 11 - 6
R-55e /July 2005
