AudioArts Engineering audio console r-55e - Page 78

W#
ITEM#
QTYDESCRIPTION
CRS-55e CONTROL ROOM/STUDIO MODULE PARTS LIST
435010R37 1332 OHM 1% .25W MC1206 RESISTOR
435013R28, R30, R36, R38, R39 5619 OHM 1% .25W MC1206 RESISTOR
435015R123, R126, R128 31.00 KOHM 1% .25W MC1206 RESISTOR
435017R32, R87, R98, R174, R194 51.69 KOHM 1% .25W MC1206 RESISTOR
435018R40, R72, R188, R189 42.00 KOHM 1% .25W MC1206 RESISTOR
435020R74, R120 22.43 KOHM 1% .25W MC1206 RESISTOR
435021R90, R92, R94, R162, R164, R166, R168, R170 83.32 KOHM 1% .25W MC1206 RESISTOR
435023
R23, R24, R31, R33, R65, R66, R88, R89, R99,
R102, R109, R110, R136, R137, R175
154.99 KOHM 1% .25W MC1206 RESISTOR
435025R96, R100 26.19 KOHM 1% .25W MC1206 RESISTOR
435028
R5, R8, R11, R14, R19, R22, R25, R26, R43, R45,
R47, R50, R51, R54, R56, R58, R59, R61
1810.0 KOHM 1% .25W MC1206 RESISTOR
435028
R63, R64, R67, R69, R75-R86, R91, R93, R95,
R105, R108, R111, R114, R122, R125, R130
2610.0 KOHM 1% .25W MC1206 RESISTOR
435028
R132, R134, R135, R138, R139, R141, R143-R145,
R153, R154, R163, R165, R167
1410.0 KOHM 1% .25W MC1206 RESISTOR
435028R169, R171, R185, R186, R191, R192 610.0 KOHM 1% .25W MC1206 RESISTOR
435032R158, R173, R187 315.0 KOHM 1% .25W MC1206 RESISTOR
435034R97, R101 220.0 KOHM 1% .25W MC1206 RESISTOR
435039
R1, R2, R29, R34, R35, R41, R71, R73, R117, R121,
R124, R127, R129, R146, R155, R159
1640.2 KOHM 1% .25W MC1206 RESISTOR
435039R172, R177-R184, R190, R193 1140.2 KOHM 1% .25W MC1206 RESISTOR
435043R176 188.7 KOHM 1% .25W MC1206 RESISTOR
500021CR1 110K TRIM POT
500029STUDIO/HDPN/CR POT 310K POT, DUAL AUDIO
510063TB SWITCH 1
DPDT PUSHBUTTON SWITCH, MOMENTARY ACTION,
GRAY HOUSING
510113SW2-SW7 62 POLE PUSHBUTTON SWITCH, MOMENTARY
510282SW1 17 POSITION RIGHT ANGLE DIP SWITCH
520038STUDIO/HDPN/CR KNOB 315mm GREY COLLET KNOB FOR 1/4" SHAFT
530039CR POT CAP 111mm BURGANDY CAP W/WHITE LINE FOR 15mm KNOB
530045STUDIO POT CAP 111mm BLUE CAP W/WHITE LINE FOR 15mm KNOB
530060TB SWITCH CAP 1LB STYLE YELLOW BUTTON
530080HDPN POT CAP 1CREAM CAP W. BLACK LINE FOR 15MM KNOB
530083
EXT1/EXT2/PGM/AUD/MONO/PRE SWITCH
BUTTON
6CUSTOM WHITE LIGHT PIPE BUTTON
605010DS1, DS2 2HIGH INTENSITY AMBER SMT LED RIGHT ANGLE
605017DS3 1ULTRABRIGHT RIGHT ANGLE RED SMT LED
605018DS4 1ULTRABRIGHT RIGHT ANGLE GREEN SMT LED
605019DS5, DS6 2ULTRABRIGHT RIGHT ANGLE YELLOW SMT LED
700649PCB_CR2000A 1PRINTED CIRCUIT BOARD SMT
8200474D SUB STANDOFFJACK HARDWARE 3/16" LONG
8210094PEM FASTENERS
page 11 - 8
R-55e / July 2004
