SPN-55e SUPERPHONE MODULE PARTS LIST
510063ON/OFF SWITCH 2
DPDT PUSHBUTTON SWITCH, MOMENTARY ACTION,
GRAY HOUSING
510097SW2-SW6 52 POLE PUSHBUTTON SWITCH, ALTERNATE ACTION
510282SW1 17 POSITION RIGHT ANGLE DIP SWITCH
520052FADER KNOB 1BLUE FADER KNOB WITH WHITE LINE
530057ON SWITCH CAP 1LB STYLE RED BUTTON
530060OFF SWITCH CAP 1LB STYLE YELLOW BUTTON
530083CUE SWITCH BUTTON 1CUSTOM WHITE LIGHT PIPE BUTTON
530272PGM/AUD/MONO/PRE SWITCH BUTTON 4SOLID WHITE LUMA-230 BUTTON
540064FADER 1100MM STEREO AUDIO ALPS FADER TYPE "K"
600031OFF SWITCH LED 1YELLOW LED FOR R5 ON/OFF SWITCH
600077ON SWITCH LED 1RED LED FOR R5 ON/OFF SWITCH
605017DS1, DS5 2ULTRABRIGHT RIGHT ANGLE RED SMT LED
605018DS2 1ULTRABRIGHT RIGHT ANGLE GREEN SMT LED
605019DS3, DS4 2ULTRABRIGHT RIGHT ANGLE YELLOW SMT LED
700657PCB_SPN2000 1PRINTED CIRCUIT BOARD SMT
8200472D SUB STANDOFFJACK HARDWARE 3/16" LONG
8210093PEM FASTENERS
835001F1-F3 3FUSE/ POLYSWITCH .3AMP SMT RESETABLE
page 11 - 14
R-55e / Sep 2010
