AudioCodes Mediant 800B Hardware Installation Manual

Gateway & E-SBC 11 Mediant 800
Hardware Installation Manual 1. Introduction
1 Introduction
This document provides a hardware description of the Mediant 800 Gateway and E-SBC
(hereafter referred to as device) and step-by-step procedures for mounting and cabling the
device.
The device supports the following interfaces (customer ordered):
 E1/T1 (PRI):
• Mediant 800B: Up to 2 E1/T1 port interfaces (over single copper wire pair).
• Mediant 800C: Up to 4 E1/T1 port interfaces
 Up to 8 BRI ports (supporting up to 16 voice channels).
 Up to 12 FXS port interfaces.
 Up to 12 FXO port interfaces.
 12 LAN Ethernet interfaces - up to 4 Gigabit Ethernet ports and up to 8 Fast Ethernet
ports. These ports operate in port-pair redundancy, providing up to 6 port-pair groups.
 Open Solutions Network (OSN) server platform for hosting third-party applications
such as an IP PBX.
 Power:
• Mediant 800B: Single AC power inlet
• Mediant 800C: Single AC power inlet, and a DC power inlet (optional, customer
ordered)
Notes:
• Mediant 800 includes two hardware revisions which differ as follows:
√ Mediant 800B: Max. 2 E1/T1; AC power only
√ Mediant 800C: Max. 4 E1/T1; AC and DC power (optional)
• Hardware configurations may change without notice. Currently available hardware
configurations are listed in AudioCodes Price Book. For available hardware
configurations, contact your AudioCodes sales representative.
• The Fast Ethernet ports are available only on "pure" SBC Mediant 800 (i.e., without
PSTN / Gateway interfaces).
• For software configuration, refer to the User's Manual.

AudioCodes Mediant 800B Specifications

General

Brand	AudioCodes
Model	Mediant 800B
Category	Gateway
Language	English
