AudioCodes Mediant 800B - Front Panel Description; Ports and Buttons; Figure 3-1: Mediant 800 B Front Panel; Figure 3-2: Mediant 800 C Front Panel

Hardware Installation Manual 16 Document #: LTRT-10689
Mediant 800
3.2 Front Panel Description
The front panel provides the telephony port interfaces, various networking ports, reset pinhole
button, and LEDs.
3.2.1 Ports and Buttons
The device's front panel is shown in the figure below and described in the subsequent table.
Figure 3-1: Mediant 800B Front Panel
Figure 3-2: Mediant 800C Front Panel
Note: The figures above are used only as an example. The number and type of port
interfaces depends on the ordered model.
Table 3-2: Front Panel Description
Item # Label Description
1 Mediant 800B:
POWER /
STATUS
Mediant 800C:
AC PWR / DC
PWR / STATUS
Power and operating status LEDs. For more information, see Section
3.2.2 on page 18.
