3.2.2.7 Power LEDs
The power LEDs depend on the Mediant 800 model.
3.2.2.7.1 Power LED
The POWER LED indicates the power supply status, as described in the table below.
Table 3-9: POWER LED Description
LED
Color
LED
State
Description
Green On Power is received by the device.
- Off No power received by the device.
Note: The POWER LED is applicable only to Mediant 800B.
3.2.2.7.2 AC PWR LED
The AC PWR LED indicates the AC power supply status, as described in the table below.
Table 3-10: AC PWR LED Description
Color State Description
Green On AC power is received by the device.
- Off No power received by the device.
Note: The AC PWR LED is applicable only to Mediant 800C.
3.2.2.7.3 DC PWR LED
The DC PWR LED indicates the DC power supply status, as described in the table below.
Table 3-11: DC PWR LED Description
Color State Description
Green On DC power is received by the device.
- Off No power received by the device.
Note: The DC PWR LED is applicable only to Mediant 800C.
