AUMA SAVEx Series - Page 67

Speed internal 4 M1933
Speed rem. min. M1936
Speed rem. max M1937
Default value: according to order data
Setting range: The adjustable speed range is indicated on the actuator name plate.
Select main menu
1. Set selector switch to position 0 (OFF).
2.
Press push button C Setup and hold it down for approx. 3 seconds.
➥
Display goes to main menu and indicates: ▶ Display...
Select parameter
3. Select parameter either:
→
click via the menu to parameter, or
→
via direct display: Press and enter ID, e.g.: M1930.
➥
Display indicates: Speed internal1
Selection:
4.
Use Up ▲ Down ▼ to select:
→
▶ Speed internal1 M1930
→
▶ Speed internal2 M1931
→
▶ Speed internal3 M1932
→
▶ Speed internal 4 M1933
→
▶ Speed rem. min. M1936
→
▶ Speed rem. max M1937
➥
The black triangle ▶ indicates the current selection.
5.
Press Ok.
➥
Display shows the set value.
➥
The bottom row indicates: Edit Esc
6.
Press Edit.
➥
Display indicates:
-
Specialist (4) → continue with step 7
-
in bottom row Up ▲ Down ▼ Esc → continue with step 11
Log on user
7.
Use Up ▲ Down ▼ to select user:
Information: Required user level: Specialist (4) or higher
➥
The symbols have the following meaning:
-
black triangle: ▶ = current setting
-
white triangle: ▷ = selection (not saved yet)
8.
Press Ok.
➥
Display indicates: Password 0***
9.
Enter password (→ enter password).
➥
Display shows the set value.
➥
The bottom row indicates: Edit Esc
10.
Press Edit.
Change value
11.
Enter new value for speed via Up ▲ Down ▼.
Information: The adjustable speed range is shown in round brackets.
12.
Save new value via Save.
➥
Speed setting is complete.
13.
Return to step 4 (Selection): Press Esc.
