Please state device type and our order number (see name plate) when ordering spare parts. Only original AUMA spare parts should be used.
Failure to use original spare parts voids the warranty and exempts AUMA from any liability. Representation of spare parts may slightly vary
from actual delivery.
TypeDesignationRef. no.TypeDesignationRef. no.
Sub-assemblyScrew plug539.0Sub-assemblyBearing flange002.0
Sub-assemblyHandwheel with ball handle542.0Sub-assemblyHollow shaft003.0
Sub-assemblyOutput drive types B/B1/B2/B3/B4/C/E549.0Sub-assemblyDrive shaft005.0
Output drive sleeve B/B1/B2/B3/B4/C/E549.1Motor coupling005.1
Parallel key551.1Manual drive coupling005.3
Sub-assemblyMechanical position indicator553.0Worm wheel006.0
Sub-assemblySocket carrier for motor plug/socket con-
nector with cable harness
554.0Sub-assemblyManual gearing009.0
Sub-assemblyPotentiometer as position transmitter556.0Sub-assemblyTorque lever017.0
Sub-assemblyPotentiometer without slip clutch556.1Gear segment018.0
Sub-assemblyHeater557.0Crown wheel019.0
Sub-assemblyBlinker transmitter including pins at wires
(without impulse disc and insulation plate)
558.0Sub-assemblyDrive pinion II for torque switching022.0
Sub-assemblyElectromechanical control unit with
switches, including torque switching heads
559.0-1Sub-assemblyOutput drive wheel for limit switching023.0
Sub-assemblyElectronic control unit with magnetic limit
and torque transmitter (MWG)
559.0-2Sub-assemblyDrive wheel for limit switching024.0
Sub-assemblySwitch stack for direction OPEN560.0-1Sub-assemblyLocking plate025.0
Sub-assemblySwitch stack for direction CLOSE560.0-2Sub-assemblyCable for protective earth058.0
Sub-assemblySwitch for limit/torque560.1Sub-assemblyMotor (only for V... motors incl. ref. no.
079.0)
070.0
Switch case560.2Sub-assemblyPlanetary gearing for motor drive (only for
V... motors)
079.0
Sub-assemblyRWG position transmitter566.0Sub-assemblyReduction gearing155.0
Sub-assemblyPotentiometer for RWG without slip clutch566.1Sub-assemblyCover500.0
Sub-assemblyPosition transmitter board for RWG566.2Sub-assemblyEx plug/socket connector with screw-type
terminals (KP, KPH)
501.0
Sub-assemblyCable set for RWG566.3Screw for control terminal501.1
Sub-assemblySlip clutch for potentiometer567.1Washer for control terminal501.2
Stem protection tube (without cap)568.1Screw for power terminal501.3
Protective cap for stem protection tube568.2Washer for power terminal501.4
V-seal568.3Sub-assemblyPin carrier without pins502.0
Threaded sleeve568.4Sub-assemblyPin for controls505.0
Stem nut A (without thread)575.1Sub-assemblyPin for motor506.0
Sub-assemblyMotor coupling on motor shaft583.0Sub-assemblyCover for electrical connection507.0
Pin for motor coupling583.1Sub-assemblyThreaded plug511.0
Sub-assemblyRetaining spring for motor coupling584.0Sub-assemblyOutput drive type A (without stem nut)514.0
Sub-assemblyEWG position transmitter614.0Sub-assemblyAxial needle roller bearing514.1
MWG 05.03 cover627.0Radial seal for output drive type A514.2
SetSeal kit, smallS1Sub-assemblyOutput drive type D516.0
SetSeal kit, largeS2Output drive shaft D516.1
Snap ring535.1
97
SAVEx 07.2 – SAVEx 16.2 / SARVEx 07.2 – SARVEx 16.2 Control unit: electronic (MWG)
ACVExC 01.2 Non-Intrusive Modbus RTU Spare parts
