Autic System Marine PC Rev. 1.1 Page 17
USING THE PANEL PC
ON-OFF AND RESET BUTTONS
The On-Off button is at the rear side of the Panel PC. This button shuts down the system in a proper way. We
strongly recommend to first shut down the system via application software or operating system.
IMPORTANT!
Do not use the Reset button for normal restart! This button makes a hard reset of the system, and may cause
abnormal behavior for the operating system.
REMOTE ON-OFF SWITCH
Remote button/switch can control on-off operation of the Box PC. Attach a potential free Switch or relay for
operation.
Toggle function.
When Panel PC is off. Single touch/pulse will start the unit.
When Panel PC is on. Single touch/pulse will stop the unit.
RESTORE ON AC/POWER LOSS
The Restore on AC/Power loss is hard coded to “Power On”. Regardless of the value set in BIOS, the PC powers
on when the AC/power is restored.
