Autic Syste
m Marine PC
Rev. 1
.1
Page
35
I
N
S
T
A
L
L
A
T
I
O
N
M
E
T
H
O
D
S
There are four methods for in
stallation. Quick mountin
g is the standard method.
Quick mounting fittings
10 screws with nuts behind fron
t bezel.
4 screws through holes in the front
bezel. Suitable when th
ere is no access from r
ear. This mountin
g is
optional.
Prepared for VESA standard bracket a
t rear side.
Various sizes accordin
g to size of monitor
.
34
36
