Autic Syste
m Marine PC
Rev. 1
.1
Page
23
Internal Connectors
USB
6 (2 x USB 3.0, 4 x US
B 2.0)
LVDS/Inverter
1/1
VGA
0
Serial
2 (RS232)
SATA
2 x SATA2(3.0Gb/s)
mPCIe
1
Parallel (LPT)
1
mSATA
1(shared)
IrDA
0
GPIO
8-bit 4 x GPI + 4 x GPO
SATA PWR
Output Con
1
Speaker
He
ader
1
Watchdog Timer
Output
Output from super I/O to d
rag RESETCON#
Interval
256 Segments, 0,1,2…255 S
ec/Min
Power Requirements
Input
PWR 9-19V DC-In (4
-pin ATX PWR Con)
Power On
AT/ATX Supported
-AT : Directly PWR on a
s power input ready
-ATX : Press button to
PWR on after power input ready
Environment
Temperature
0ºC
–
60ºC
22
24
Table of Contents
Default Chapter
1
Installation and User Manual
1
Contents
3
Table of Contents
3
About the Autic Marine PC Product Series
6
Autic Panel PC
6
Range of Panel PC Products
7
Product Identification
7
Specifications Panel PC
8
Technical Data
8
Supported Operating Systems
8
Motherboard Specification
9
Panel PC Connectors
11
I/O Panel
12
COM Ports
12
Ethernet
13
Usb
13
Installing the Panel PC
14
Package Contents
14
Mechanical Installation
14
Compass Safety Distance
14
Installation Methods
15
Electrical Installation
16
Verification
16
Using the Panel PC
17
On-Off and Reset Buttons
17
Remote On-Off Switch
17
Restore on Ac/Power Loss
17
Monitor Adjustment, Models with High Brightness
18
Autic Box PC
19
Range of Box PC Products
20
Product Identification
20
Specifications Box/Mini PC
20
Technical Data
21
Supported Operating Systems
21
Motherboard Specification
22
Box PC Connectors
24
I/O Panel
25
COM Ports
25
Ethernet
26
Usb
26
Installing the Box/Mini PC
27
Package Contents
27
Mechanical Installation
27
Compass Safety Distance
27
Installation Options
27
Electrical Installation
28
Verification
28
Using the Box/Mini PC
29
On-Off and Reset Buttons
29
Remote On-Off Switch
29
Restore on Ac/Power Loss
29
Autic Marine Monitors
30
Range of Products
31
Product Identification
31
Specification Monitors
32
Technical Data
32
Monitor Connectors
33
Installing the Monitor
34
Package Contents
34
Mechanical Installation
34
Compass Safety Distance
34
Installation Methods
35
Electrical Installation
36
Verification
36
Using the Monitor
37
Monitor Adjustments
37
Monitor Adjustments (Old Version)
38
Product Dimensions
39
Panel PC Dimensions
39
Panel PC 4:3 Models
40
Panel PC 16:9 Models
43
Box/Mini PC Dimension
45
Monitor Dimensions
46
UEFI and BIOS Settings
47
Introduction
47
UEFI Menu Bar
47
Navigation Keys
48
Main Screen
48
Advanced Screen
49
Instant Flash
49
CPU Configuration
50
Chipset Coniguration
51
Storage Configuration
52
Intel® Smart Connect Technology
53
Super IO Configuration
53
ACPI Configuration
54
USB Coniguration
55
Hardware Health Event Monitoring Screen
55
CPU_FAN1 Setting
55
CHA_FAN1 Setting
56
Case Open Feature
56
Clear Status
56
Security Screen
56
Supervisor Password
56
User Password
56
Secure Boot
56
Boot Screen
57
Fast Boot
57
Boot from Onboard LAN
57
Setup Prompt Timeout
57
Bootup Num-Lock
57
Boot Beep
57
Full Screen Logo
57
CSM (Compatibility Support Module)
58
Exit Screen
58
Save Changes and Exit
58
Discard Changes and Exit
58
Discard Changes
58
Load UEFI Defaults
58
Launch EFI Shell from Filesystem Device
59
Operating System
59
Customer Specified or Trial Version
59
Shutting down Properly
59
Declaration of Conformity for LCD Display
60
Service
61
Return of Products to Autic System
61
Accessories
62
