4007ES Operator’s Manual
8.1.3 Panel Serial Number
Serial Number
Appears Here
Panel Serial Number
Date
Time
100%
Tap the Serial Number button to see the serial number of the panel.
8.1.4 Card Status
Card Status
Appears Here
Select Card for Status
Date
Time
100%
Tap the Card Status button to see the status of the different cards installed in the panel.
8.1.5 System Files Info
BOOTLOADER REV: 1.01.00.03
KERNEL REV: 1.01.00.10
FILESYSTEM REV: 1.01.01.15
PANELUI: 1.01.02.16
System Files Info
Date
Time
100%
Tap the System Files Info button to see the latest master revisions loaded on the Remote
Annunciator.
8.1.6 IP Info
IP ADDRESS: 192.168.1.150
HARDWARE ADDRESS:
00:08:bd:01:dc:43
IP Info
Date
Time
100%
Tap the IP Info button to see the IP and the MAC address of the 4007ES panel.
