5 - 8
5 Electrical Components
5
5.1-2 Supply voltage / line connection order
The supply voltage in the electrical cabinet is named
• L01 - L09: Power voltage
• L10 and above: Control voltage
Please note that the conductors used on this machine have coloured insulation
which may be a single (Base) colour Single(Base) colour with a narrow spiral Trace
of different colour.
Due to lack of space, these colours are marked on the circuit and connection
diagrams using a number colour code or a letter colour code. Colour codes may be
follwoed by a dash and a number which indicates that this colour wire has been
used in another circuit.
Letter Code: BBTT - C meaning Base Colour (two letters) - Circuit number example
WhBk-2 = White wire with Black trace - 2nd circuit (used second time)
Wh - 2 = White wire used second time
The letter colour code as below:
Bk = Black, Bn = Brown, Rd = Red, Og = Orange, Ye = Yellow,
Gn = Green, Bu = Blue, Vt = Violet, Gy = Grey, Wh = White, Pk = Pink
