1 Introduction
1-7
1
d) Film Welding and Cutting - Permanently heated bar with PID Electronic
temperature control. Quickly removable, welding-cutting tip ease of
maintenance. Welding bar height is adjustable with a quick-set clamp.
e) Film Feed - Centre shaft, film roll support with gravity feed, controlled by
multiloop film accumulators. AC motor driven twin roller cradle type support is
optional.
f) Film Loading - film rolls are mounted right at front of machine to facilitate ease
of loading and minimize risk of operator injury.
g) Transfer Surfaces - Collating table is lined with UHMW polyethylene to
minimize friction and wear. Outfeed table and slide are stainless steel.
h) Safety - Low pressure welding bar descent with electrical trip, two Stop
Buttons. Electrically interlocked transparent doors around collation table area.
For Tunnel
a) Control System - simple Relay/contactor circuit with some electronic control
b) Conveyor Drive - gear motor. fixed or variable speed depending on application
c) Conveyor Belt - stainless steel mesh for general purpose tunnels. STH uses
heavy duty chain with flat bars for product conveying.
d) Air Circulation - two or Four centrifugal force impellers are used to provide
symmetrical air pattern.
e) Heating - finned type air heating elements controlled by PID Electronic
Temperature control unit.
f) Outfeed accumulation conveyor - free running roller type accumulation
conveyor is provided.
g) Safety - the machine is well guarded. Where possible standard stainless
conveyor of small pitch is used. Two stop buttons are provided on either side of
the tunnel for emergency use.
1.2-2 Machine Design
AUTOPACK designers pay particular attention to specifying materials and finishes
that are durable, does not affect the packaged product and remain serviceable for
long time.
Manufacturer
This equipment was produced by:
Autopack Co., Ltd.
98/50 Moo 11 Putthamonthon Sai 5 Rd.,
Samphran, Nakornpathom
73210 THAILAND
