6-7
Group Description Page No
Assembly Drawing:
Pos Part No Qty UN Description
Pos Part No Qty UN Description
AANVI13246-01
ANVIL BAR FOR 45W G
010 DRSB132460-00 1 ANVIL BAR 460mm. AL
030 DRUB132461-00 1** RUBBER PAD FOR 45W GRAY
040 DTEF152460-00 1** ANVIL SHIELD (TEFLON 50x.075 460mm.)
060 DCHA132452-00 1 CHANNEL-26x450 2ø 10.5 45W5 SS
AANVI13260-00
ANVIL BAR FOR 60W R
010 DRSB132610-00 1 ANVIL BAR 610mm. AL
030 DRUB132610-00 1** RUBBER PAD FOR 60W RED
040 DTEF152610-00 1** ANVIL SHIELD (TEFLON 50x.075 610mm.)
060 DCHA132602-00 1 CHANNEL-26x600 2ø 10.5 60W5 SS
AANVI13280-00
ANVIL BAR FOR 80W R
010 DRSB132810-00 1 ANVIL BAR 810mm. AL
030 DRUB132810-00 1** RUBBER PAD FOR 80W RED
040 DTEF152810-00 1** ANVIL SHIELD (TEFLON 50x.075 810mm.)
060 DCHA132802-00 1 CHANNEL-26x800 2ø 10.5 80W5 SS
COMMON PART
020 DPIN0A1250-00 2 LATCH PIN SS
050 FSCR050K0-0S 2 SCREW SOCSET M5x20 SS
Sensor prox. 12mm. with pre-wired (if used)
ESEI120C4-0O 1** Sensor Ind 24V 12D PNP 4mm.Om
Sensor prox. 12mm. with connector cable (if used)
ESEI120C4-1O1 1** SensorInd24V12D PNP4mm.Om Body
ECAB0402C-2O 1** CableConn M12 90Degree 2m Om
** - compalsory parts
Rubber pad and Teflon can be supplied in the rolls.
Here is information for materials in rolls:
RTEF153A0-0P 1 TEFLON SHIELD50mmx10M ROLL
or
RTEF15060-0P 1 TEFLON SHIELD 50x.075 30m ROLL
DRUB132461-00 1 ANVIL RUBBER PAD FOR 45W
DRUB132610-00 1 ANVIL RUBBER PAD FOR 60W
DRUB132810-00 1 ANVIL RUBBER PAD FOR 80W
Optional stock
ETEM22030-1O 1 TEMPERATURE CONTROL 220v Rel Om
AWEL13245-00 1 CLIP IN WELDING BAR ASS.
AANV12346-01 1 CLIP IN ANVIL BAR ASS.
PVAS02121-0F 1 VALVE 1/4 P-5 CW COIL 24DC F
EMOT241J3-0S 1 MOTOR AC 380V .18KW D63/4P B5 SI
EMOT24244-0S 1 MOTOR .37KW 4P 3PH FLANG SIEM
MGEA14120-2M 1 CONVEYOR GEARBOXMOTOVARIO20:1
MGEA130F0-1M 1 Gearbox 30 1:15 11/90 Moto
MGEA130A0-1M 1 Gearbox 30 1:15 11/90 Moto
ETEM22030-1O 1 Temperature Contrl 220V Rel Om
EINV53715-1F 1 Inverter EMC filter 0.4KW Fuji
ESSR26145-0C 1 SSR-600AC 50A 4-30DC In Celduc
NOTE:
Please supply the model and serial number of each machine when ordering spare parts.
SPARE PARTS
ANV13261
