Autopack 45WLO20FP - Page 99

6-9
Group Description Page No
Assembly Drawing:
Pos Part No Qty UN Description
Pos Part No Qty UN Description
COMPULSORY SPARES:
RUBBER CURTAIN
For 45T
DCUR452000-00 2** RUBBER CURTAIN for 45Tx20
DCUR452500-00 2** RUBBER CURTAIN for 45Tx25
DCUR453000-00 2** RUBBER CURTAIN for 45Tx30
DCUR450000-00 2** RUBBER CURTAIN for 45Tx35
DCUR454000-00 2** RUBBER CURTAIN for 45Tx40
For 60T
DCUR602000-00 2** RUBBER CURTAIN for 60Tx20
DCUR602500-00 2** RUBBER CURTAIN for 60Tx25
DCUR603000-00 2** RUBBER CURTAIN for 60Tx30
DCUR603500-00 2** RUBBER CURTAIN for 60Tx35
DCUR604000-00 2** RUBBER CURTAIN for 60Tx40
For 62T
DCUR622000-00 2** RUBBER CURTAIN for 62Tx20
DCUR622500-00 2** RUBBER CURTAIN for 62Tx25
DCUR623000-00 2** RUBBER CURTAIN for 62Tx30
DCUR623500-00 2** RUBBER CURTAIN for 62Tx35
For 80T
DCUR802000-00 2** RUBBER CURTAIN for 80Tx20
DCUR802500-00 2** RUBBER CURTAIN for 80Tx25
DCUR803000-00 2** RUBBER CURTAIN for 80Tx30
DCUR803500-00 2** RUBBER CURTAIN for 80Tx35
DCUR804000-00 2** RUBBER CURTAIN for 80Tx40
For 82T
DCUR822500-00 2** RUBBER CURTAIN for 82Tx25
DCUR822000-00 2** RUBBER CURTAIN for 80Tx20
DCUR823000-00 2** RUBBER CURTAIN for 80Tx30
DCUR823500-00 2** RUBBER CURTAIN for 80Tx35
DCUR824000-00 2** RUBBER CURTAIN for 82Tx40
OPTIONAL SPARES:
ETEM22030-1O 1 Temperature Contrl 220V Rel Om
EOVE24040-0T 1 OverLoad Rel 4A. 1.5KW Tele.
MWHE221A0-1G 1 FANWHEEL 200x100x14 ACW GAL CA
MWHE221A0-0G 1 FANWHEEL 200x100x14 CW GAL CA
MWHE221A0-1S 1 FANWHEEL 200x100x14 ACW S/S
MWHE221A0-0S 1 FANWHEEL 200x100x14 CW S/S
EFAN22230-0G 1 FAN UNIT 220V 12” DIA STM
EINV53715-1F 1 Inverter EMC filter 0.4KW Fuji
ESSR26145-0C 1 SSR-600AC 50A 4-30DC In Celduc
EMOT24244-0S 1 **MOTOR .37KW 4P 3PH FLANG SIEM
WIRE BELT FOR 45TM:
MBEL242A00-W 1 Belt wire 356Wx7.26Px1.69945T3.9M
WIRE BELT FOR 45TH:
MBEL242A00-W 1 Belt wire 356Wx7.26Px1.69945T5.8M
WIRE BELT FOR 60TM:
MBEL252AO-OW 1 Beltwire 508Wx7.26p.ss60T3.9M
WIRE BELT FOR 60TH:
MBEL252AO-OW 1 Beltwire 508Wx7.26p.ss60T5.8M
WIRE BELT FOR 80TM:
MBEL272AO-OW 1 Belt wire 711Wx7.26P80ss3.9M
WIRE BELT FOR 80TH:
MBEL272AO-OW 1 Belt wire 711Wx7.26P80ss5.8M
NOTE:
Please supply the model and serial number of each machine when ordering spare parts.
** - compalsory parts
SHRINK TUNNEL SPARE PARTS
