Electrical Connection
Caution:
This valve and control are for dry location
use only unless used with a Listed Class 2 power
supply suitable for outdoor use.
The 764 Series control operates on a 12-volt alternating
current power supply. This requires use of the Pentair
Water supplied AC adapter. A variety of AC adapters
are available from your supplier for different
applications. They include:
120 VAC AC Adapters:
Make sure power source matches the rating printed on
the AC adapter.
Note: The power source should be constant. Be
certain the AC adapter is not on a switched outlet.
Power interruptions longer than 8 hours may cause the
controller to lose the time and day settings. When
power is restored, the control will display four dashes
(- - :- -) indicating that the day and time settings must
be re-entered
Note: Do not connect power by plugging in the
transformer at this time. Doing so may cause difficulty
in properly placing the unit into operation.
Caution:
Plumbing cannot be used for electrical
grounding when metal inlet and outlet piping is
connected to a non-metal valve.
Connect the inlet and outlet piping together using a
grounding strap or clamp to establish continuity.
AC Adapter
Input
Voltage
Application
Part
Number
Standard wall-
mount
120V 60 Hz
UL listed for
indoor
installations
1000811
Outdoor rated 120V 60 Hz
UL listed for
outdoor
installations
1235448
