28
Level IV Viewing History - H Values
Historical information can be viewed by pressing the
SET and DOWN buttons simultaneously, with the
764 control in the home position. Release both buttons
when the control displays an “H” value. Press the UP or
DOWN buttons to navigate to each setting.
Table-6 History Data
H# Description Range Notes
H0
a
Initial Setting Value Cubic Feet or Liters Resin Volume
H1 Days since last regeneration 0 - 255
H2 Current Flow Rate Depends on turbine used
H3 Water used today in gallons or/m
3
since Time of Regeneration 0-131,070 or 0-1,310.70 m
3
H4 Water used since last regeneration in gallons or/m
3
0-131,070 or 0-1,310.70 m
3
H5
a
Total water used since reset in 100s
0-999900 gallons or
0-9999 m
3
H6
a
Total water used since reset in 1,000,000
4,294 x 10
6
gal or
4264 x 10
4
m
3
H7 Average usage for Sunday in gallons or m
3
0-131,070 gallons
or 0-1,310.70 m
3
H8 Average usage for Monday in gallons or m
3
0-131,070 gallons
or 0-1,310.70 m
3
H9 Average usage for Tuesday in gallons or m
3
0-131,070 gallons
or 0-1,310.70 m
3
H10 Average usage for Wednesday in gallons or m
3
0-131,070 gallons
or 0-1,310.70 m
3
H11 Average usage for Thursday in gallons or m
3
0-131,070 gallons
or 0-1,310.70 m
3
H12 Average usage for Friday in gallons or m
3
0-131,070 gallons
or 0-1,310.70 m
3
H13 Average usage for Saturday in gallons or m
3
0-131,070 gallons
or 0-1,310.70 m
3
H14 Average service cycle 0-255 days
H15
a
Peak Flow Rate 0-200 gpm or 1000 Lpm
H16 Day and Time of Peak Flow Rate
Time and day that peak flow
occurred
H17
a
Months since service 0-2184 months
H18 Water used since last regeneration - Tank 1
0-131,070 gallons
or 0-1,310.70 m
3
H19
a
Water used since last regeneration - Tank 2
0-131,070 gallons
or 0-1,310.70 m
3
Hr Number of regenerations since last serviced 0-65536
a. H0, H5, H6, H15, H17, H19 values can be reset by pressing and holding for 3 seconds while the values
are being displayed.
