AUX Air Conditioner Service manual
47
Section 7 Explosion View
1. Indoor Unit:
Model eg: ASW-H09A4/HS2R-IVA ASW-H09A4/HS2R-IVB
ASW-H12A4/HS2R-VA ASW-H09A4/HS2R-VB
ASW-H12A4/HS2R-VIA ASW-H12A4/HS2R-VIB
