AUX Air Conditioner Service manual
48
Parts List
No. Part Name Quantity Remark
1 Panel assembly 1 Depend on the panel
style of individual model
2 Filter 2
3 Cover board of electrical unit 1
4 Cover of medium frame 1
5 Horizontal air blade 1
6 Vertical air blade 12
7 Air blade holder 1
8 Step motor 1
9 Through-flow fan 1
10 Rubber bearing holder 1
11 Plastic holder for left cruch of evaporator 1
12 Evaporator assembly 1
13 chassis 1
14 Mounting plate 1
15 Clamp of copper pipe 1
16 Indoor fan motor 1
17 Controller box 1
18 Transformer 1
19 Indoor sensor 1
20 Main PC board 1
21 Evaporator tube sensor 1
22 Remote manipulator acceptor 1
23 Temperature control probe holder 1
24 Receiver board 1
25 Terminal board 1
26 Anion generator 1 Optional
27 Signal connection wire 1（2） 1 Correspondent with A. B
indoor unit
29 Power line 1
30 Display board 1
31 Remote controller 1
