AUX EA Series User Manual

AUX Air Conditioner Service manual
2
Section 2 Technical Specifications
ASW-H09A+09A4/HS2R-IV
Model No
Items
Indoor Unit A
(System A)
Indoor Unit B
(System B)
Outdoor Unit
Type Wall mounted model Heating pump
Cooling kw 2.5 2.5 /
Dehumidify kg/h 1.0 1.0 /
Heating kw 2.75 2.75 /
Noise level dB(A) 40 40 62
Cooling 2.3 2.3 /
Performance
EER
Heating
W/W
2.4 2.4 /
Power supply φ-V-Hz 1 / 220-240V~/ 50Hz
Cooling 1060 1050 2030
Rated input
Heating
W
1070 1060 2000
Cooling 4.60 4.56 8.83
Rated current
Heating
A
4.65 4.60 8.7
Length m 2 2 4.8
Supply cord
Class / 250V 10A 250V 10A 400V 25A
Starting Current A 21.7 21.7 /
Electrical Data
Fuse capacity A 3.15 3.15 3.15
Refrigerant/Charge g R407c/700 R407c/730 /
Type / Rotary Rotary /
Model /
PG165X1C-4DFDE2 PG165X1C-4DFDE2
/
Rated input W 955/980 955/980 /
Compressor
Overload
Protector
/ MRA13430-9087
B160-135-241E
MRA13430-9087
B160-135-241E
/
Heat exchanger Row*Hole 2*10 2*10 1*31
Type Capillary tube
Refrigerating System
Expansion device
Specification(mm)
φ2.6*400+φ2.6*450 φ2.6*350+φ2.6*400
/
Air Volume m3/h 420 420 /
Cooling r/min 1080/950/900/800 1080/950/900/800 860 Fan Speed
H/M/L/Q
Heating r/min 1080/950/900/850 1080/950/900/850 860
Fan type / Cross flow Cross flow Propeller fan
Fan System
Fan motor output W 19 19 68
Connecting
Pipe
Gas /Liquid OD(mm)*L(mm)
Φ9.52×5000/Φ6.35×5000
Connection
Drainage Pipe OD(mm)*L(mm)
Φ14×780
Suitable area m2 12-17 12-17 /
Net dimensions
(W x H x D)
mm 80.2*26.2*16.5 80.2*26.2*16.5 331*846*901
Others
Net weight kg 9.5 9.5 65
