AUX Air Conditioner Service manual
3
ASW-H09A+12A4/HS2R-V
Model No
Items
Indoor Unit A
(System A)
Indoor Unit B
(System B)
Outdoor Unit
Type Wall mounted model Heating pump
Cooling kw 3.2 2.5 /
Dehumidify kg/h 1.2 1.0 /
Heating kw 3.6 2.75 /
Noise level dB(A) 43 40 62
Cooling 2.3 2.3 /
Performance
EER
Heating
W/W
2.4 2.4 /
Power supply φ-V-Hz 1 / 220-240V~/ 50Hz
Cooling 1320 970 2150
Rated input
Heating
W
1360 1070 2300
Cooling 5.74 4.22 9.35
Rated current
Heating
A
5.91 4.65 10
Length m 2 2 4.8
Supply cord
Class / 250V 10A 250V 10A 400V 25A
Starting Current A 30.5 21.7 /
Electrical Data
Fuse capacity A 3.15 3.15 3.15
Refrigerant/Charge g R407c/1100 R407c/980 /
Type / Rotary Rotary /
Model /
4KS225EBB 4PS164EAC
/
Rated input W 1300/1325 920/945 /
Compressor
Overload
Protector
/ Inner B165-150-241H /
Heat exchanger Row*Hole 2*12 2*10 2*31
Type Capillary tube
Refrigerating System
Expansion device
Specification(mm)
φ3.0*500+φ3.0*500 φ2.6*350+φ2.6*300
/
Air Volume m3/h 620 420 /
Cooling r/min 1180/1050/950/800 1080/950/900/800 860 Fan Speed
H/M/L/Q
Heating r/min 1180/1050/950/850 1080/950/900/850 860
Fan type / Cross flow Cross flow Propeller fan
Fan System
Fan motor output W 19 19 68
Connecting
Pipe
Gas /Liquid OD(mm)*L(mm)
Φ9.52×5000/Φ6.35×5000
Connection
Drainage Pipe OD(mm)*L(mm)
Φ14×780
Suitable area m2 12-21 12-17 /
Net dimensions
(W x H x D)
mm 89.2*29.6*17.6 80.2*26.2*16.5 331*846*901
Others
Net weight kg 10.5 9.5 70
